Custom Framing Steel Buildings / Precision Engineered Metal Solutions for Modern Construction
As leading steel building fabricators, we specialize in framing steel building systems that redefine durability, speed, and versatility across industries. Our metal building solutions leverage advanced engineering to deliver tailored structures for diverse needs:
Heavy-duty steel structure frameworks for factories, warehouses, and power plants—including multi-bay warehouses, equipment storage units, and mezzanines—engineered to support heavy loads (up to 50 tons per bay) with minimal deflection.
Rapid-install steel building kits for offices, retail spaces, and hotels, combining sleek aesthetics with open floor plans—ideal for building a metal building projects where time-to-occupancy is critical.
Corrosion-resistant steel metal buildings for barns, equipment sheds, and livestock shelters, using galvanized steel to withstand harsh weather and extend lifespan by 30% vs. traditional materials.
Custom steel construction frameworks for bridges, rail depots, and distribution hubs, designed to handle dynamic loads (e.g., train vibrations) and seismic activity up to Zone 8.
From small steel warehouse construction projects to mega heavy steel construction installations, our framing steel building systems adapt to your site constraints, budget, and functional requirements.
| Standard | Process Details | Key Technologies |
|---|---|---|
| Design & Engineering | 3D BIM modeling with Tekla Structures; load analysis using Autodesk Robot. | Cloud-based collaboration for real-time client feedback; seismic/ wind load simulations. |
| Material Prep | Sourcing ASTM A36/A572 steel; laser cutting (±0.3mm precision) with CNC machines. | Fiber lasers for thin sheets (1-12mm); plasma cutters for thick plates (1-25mm). |
| Framing Steel Building | Roll-forming steel sections (C/Z purlins, rafters, columns) to custom radii; automated welding for primary/secondary frames. | Press brakes (1,200-ton capacity); 5-axis CNC drills for bolt hole alignment (±0.1mm). |
| Welding & Assembly | MIG/TIG welding by AWS-certified welders; full-penetration welds for critical joints (e.g., column-to-foundation connections). | Laser trackers (API T3) for frame alignment (±0.05mm tolerance); pre-assembled modules for on-site speed. |
| Finishing | Prime/paint coatings (250μm thickness) or hot-dip galvanizing (850g/m²); insulation (polyisocyanurate foam) for thermal efficiency. | Powder coating lines for color consistency; spray-applied fireproofing (2-hour rating). |
| Final Inspection | Dimensional checks (CMM machines); load testing up to 1.5x design capacity. | Third-party SGS audits; RFID tags for material traceability from mill to site. |
In framing steel building projects, structural integrity hinges on weld quality. Our processes ensure steel structure frames meet the highest standards:
Advanced Welding for Steel Frames
Primary Frames: For large-span warehouses or industrial halls, we use submerged arc welding (SAW) with ER70S-6 filler metal to achieve full-penetration welds (thickness up to 25mm), eliminating weak points in heavy steel construction.
Secondary Frames: Lightweight purlins and girts undergo MIG welding with pulsed current to reduce spatter and distortion—critical for building a metal building with tight tolerances.
Corrosion Resistance: All welds receive post-weld heat treatment (PWHT) to relieve stress, followed by galvanizing or epoxy coating to match base metal durability.
Precision Frame Inspection
Non-Destructive Testing (NDT):
X-Ray/UT: For critical joints (e.g., foundation connections), digital radiography (DR) detects 0.1mm cracks; phased-array UT identifies internal flaws in thick sections (up to 300mm).
Visual Checks: AWS-certified inspectors use 10x magnifiers to reject welds with undercutting >0.5mm or porosity >1mm.
Dimensional Accuracy: Laser trackers measure frame alignment (±0.05mm), ensuring modules fit seamlessly on-site—reducing steel warehouse construction rework by 20%.
| Standard | Protocol | Compliance |
|---|---|---|
| Material Certification | Sourcing from ISO 9001-certified mills (ArcelorMittal, Nippon Steel). | Mill Test Reports (MTRs); alloy verification via spectroscopy. |
| Frame Welding | AWS D1.1/D1.8 standards; 100% visual + NDT (X-ray/UT). | Welder qualifications per AWS QC7; defect rejection rate <0.3%. |
| Dimensional Accuracy | CMM machines (0.02mm resolution); laser scanning for large assemblies. | Tolerances within ±1mm of design; 99.5% pass rate in client inspections. |
| Coatings | Hot-dip galvanizing (ASTM A123) or powder coating (250μm). | Salt spray test (ISO 9227) ≥1500 hours; adhesion test ≥5MPa. |
| Certifications | ISO 9001, CE, ASME BPVC Section IX; OSHA-compliant safety protocols. | Annual audits by TÜV/BV; green manufacturing (90% scrap recycling). |
Modular Shipping: Disassembled steel building modules (max 12m length) packed in VCI-wrapped crates—protecting frames during transit.
Global Logistics: Partnered with Maersk/COSCO for oversized cargo; SPMT trailers enable door-to-door delivery of steel metal buildings (handling 1,000+ ton shipments).
On-Site Support: Dedicated installation teams use laser levels and torque wrenches to align frames—reducing building a metal building installation time by 40%.
